• Designed for 30 mm cage systems; • Compatible with SM1 lens tubes; • Ideal for constructing optical setups involving prisms, beamsplitters, and other 90° beam-steering components; • This page includes cubes, optic mounts, base platforms, rotation platforms, and cover plates;
The M2-W Series 30 mm Cage Cubes are ideal for building systems with prisms, beamsplitters, or other optical elements that introduce a 90° beam deviation. They are compatible with a variety of 30 mm cage cube accessories, including optical element holders, mounting platforms, rotating platforms, and cover plates, all available via this listing.
• Post diameter Ø6 mm, with M4 thread at the bottom; • Provides clamping force for mounts with platforms; • The PRK1-A65 clamping arm can hold optical elements up to 52.5 mm in size;
The PRK1-A is compatible with optical elements up to 53 mm in height. It features a Ø6 mm × 60 mm post with M4 threading (thread length: 5 mm). The distance between the post center and the nylon-tipped setscrew center is 25 mm and 35.5 mm, with 10.5 mm spacing between the two nylon screws.
